AGFA CR 30-X - Replacements at Scan Module; Replacing the Calibration Board; Replacing the Optic Module; Replacing the PMI Power Distribution Board

DD+DIS150.06E
Repair and Service
Replacements / Repair Procedures
DOCUMENT CONTROL NOTE:
The controlled version of this document resides on MedNet. Any printed copy of this document is uncontrolled.
Edition 1, Revision 2 CR 30-X Chapter 3.5 / 87
03-2009 Type 5175 / 100/110 Agfa Company Confidential
3 Replacements at Scan Module
3.1 Replacing the Calibration Board
The replacement instructions for the Calibration Board, spare part number*
CM+9 5175 2470 2, are enclosed to the spare part.
* The last digit in the spare part number indicates the spare part revision at release of this document.
When ordering, the actual revision of the spare part is delivered.
3.2 Replacing the Optic Module
The replacement instructions for the Optic Module, spare part number*
CM+9 5175 2750 0, are enclosed to the spare part.
* The last digit in the spare part number indicates the spare part revision at release of this document.
When ordering, the actual revision of the spare part is delivered.
3.3 Replacing the PMI Power Distribution Board
REQUIRED SPARE PART:
CM+9 5170 4960 0*
*0 in the spare part number indicates the spare part
revision at release of this document.
When ordering, a different revision of the spare part
may be delivered (e.g. 1).
Figure 216
