DD+DIS150
.06E
Controls, Connections, and Setup Procedures
DOCUMENT CONTROL NOTE:
The controlled version of this document resides on MedNet. Any printed copy of this document is uncontrolled.
1 Scope of this Document
This document describes the installation and configuration of the digitizer.
It is additionally required to perform installation and configuration of the
NX Workstation. Refer to Chapter 4 of the corresponding NX Workstation version in the
Mednet GSO Library: <GSO Library => Computed Radiography =>
CR Workstation Software>.
The required NX workstation documents are also available on CD-ROM as part of the
NX workstation delivery.
For installation instructions of optional digitizer components like “All-in-one Cart”, UPS
or Wall Fixation Kit refer to the accompanying document of the option.
NOTE
The PC to which the digitizer is connected to is further named in this document:
Control PC, in its function to control the digitizer.
NX Workstation, in its function to have the NX image processing software
running on it.
NOTE:
The Installation Checklist in section 8 of this chapter gives an overview of all steps
of the digitizer installat
ion and guides through the complete installation process.
2 Prerequisites for Installation
The purpose of this section is to show the required tasks before installation to
guarantee a smooth digitizer installation.
Task Required
Time
Importance Task Code* Section
Check installation site
prerequisites.
15 minutes mandatory PRI 2.1
Prepare required tools. 5 minutes mandatory PRI 2.2
*Complete required time per Task Code to be entered in the Agfa repair report.
Edition 1, Revision 5 CR 30-X Chapter 1 / 4
11-2009 Type 5175 / 100/110 Agfa Company Confidential
