AGFA CR 30-X - 3.6 Adjustments and Calibrations

HEALTHCARE
Imaging Services
Chapter 3.6
Repair and Service
Adjustments and Calibrations
Document No: DD+DIS150.06E
DOCUMENT CONTROL NOTE:
The controlled version of this document resides on MedNet. Any printed copy of this document is uncontrolled.
Edition 1, Revision 3
10-2009 printed in Germany
Agfa Company Confidential
Document Node ID: 14798434
eq_03-6_adjustments_e_template_v07
Copyright © 2009 Agfa HealthCare N.V.
CR 30-X
Type 5175 / 100/110
► Purpose of this Document
This document describes all adjustments and calibrations as well as their purpose.
► Document History
Edition.
Revision
Release
Date
Changes
compared to previous Version 1.2:
1.3 10-2009
 Added drawer adjustment tool "version 2", which allows to check
min. and max. height position. See section 2.1.

Revised PMI Board Carrier Position Adjustment and Cassette Unit
Safety Switch Position Adjustment: Replaced (pixel based) images
by vector drawings. See sections 2.2 and 2.3.
 Revised Cassette Edge Sensor Position Adjustment: Added
multimeter as optional tool. See section 2.4.

Added "laser beam check and adjustment". See section 2.5.

Revised Shading Calibration Procedure: Shifted FLFS specific items
into an appendix section. See section 3.1.

Revised Stall Calibration Procedure: Removed overview table about
which stall calibration has to be performed at which replacement, as
this is described at each replacement procedure. See section 3.2.
► Referenced Documents
Document Title
DD+DIS150.06E CR 30-X Service Documentation Chapter 3.5,
Replacements / Repair Procedures
