AGFA CR 30-X - Page 345

DRAWER
TYPE 5175/100/110
DOCUMENT CONTROL NOTE:
The controlled version of this document resides on MedNet. Any printed copy of this document is uncontrolled.
=Assembly
D =Standard part. For order please refer to the separate spare parts list for standard parts "DD+DIS011.93M"
* =No wearing part.
Pos. Nr.
Item no.
Pos. no.
Teile-Nr.
Part No.
Nr. de Ref.
Benennung
Description
Denomination
CM+9517536001
1
LÖSCHEINHEIT
ERASURE UNIT
UNITE D'EFFACEMENT
CM+9517585901
2
KABEL LÖSCHEINHEIT IP HANDLING BOARD
IP-HANDLING ERASURE CABLE
IP-HANDLING ERASURE CABLE
CM+9517590302
3
WALZENPAARE
INPUT ROLLERS
PAIRE DE ROULEAUX
CM+9517563500
4
WALZEN MOTOR - (M5)
MOTOR ROLLER - (M5)
MOTEUR DE ROULEAU - (M5)
CM+9517561006
5
TRANSPORTSCHLITTEN
DRAWER UNIT
CHARIOT DE TRANSPORT
CM+9517561250
6
MAGNET, GEKLEBT (3 STCK.)
PERMANENT MAGNETS (3 PIECES)
FIXATION, COLLÉ (3 PIÈCES)
CM+9517586900
7
TRANSPORTSCHLITTEN MOTOR - (M4)
DRAWER MOTOR - (M4)
MOTEUR DE CHARIOT TRANSPORT - (M4)
CM+9517560010
8
DRAWER ADJUSTMENT TOOL
DRAWER ADJUSTMENT TOOL
DRAWER ADJUSTMENT TOOL
CM+9949969500
9
SENSOR IR-REFLEX
ROLLER IP SENSOR
PHOTOCELLULE DE REFLEXION
CM+9517563400
10
HEBEKULISSENLAGER (1 STCK.)
BEARING FOR CONNECTING LINK (1 PIECE)
PALIER POUR COULISSE (1 PIECE)
CM+9517586800
11
MOTOR WALZENKLEMMUNG - (M6)
MOTOR ROLLER CLAMPING - (M6)
MOTEUR DE ROULEAU SERRAGE - (M6)
CM+9517598900
12
SEITENBLECH TRANSPORTEINHEIT
SIDE PLATE TRANSPORT UNIT
SIDE PLATE TRANSPORT UNIT
DD+DIS325.06M
Spare Parts List
Edition 1, Revision 3 Chapter 5 / 13CR 30-X
01-2009
Agfa Company Confidential
