Agilent Technologies 2100 Maintenance And Troubleshooting Guide

Maintenance and Troubleshooting 127
Maintenance of the Electrode Cartridge
8
How to Clean the Pin Set of the Electrode Cartridge
2 Open the lid and pull the metal lever on the inside left of the lid to the
vertical position as shown in Figure 1 on page 127. When the lever is in the
vertical position, the cartridge is released from the lid by about 10 mm.
Figure 1 Remove/replace the electrode cartridge
3 Gently pull the cartridge out of the lid as shown in Figure 1 on page 127.
0HWDOOHYHU
&DUWULGJHUHOHDVHG

Agilent Technologies 2100 Specifications

General

Brand	Agilent Technologies
Model	2100
Category	Measuring Instruments
Language	English
