Agilent Technologies E5071C Service Guide

Chapter 3 171
Adjustment
Required Adjustment after Replacing Assembly
1. Chapter Title
2. Chapter Title 3. Adjustment
4. Chapter Title
5. Chapter Title
Required Adjustment after Replacing Assembly
After replacing the following assembly, the adjustment items described in Table 3-1 must
be required. The adjustment must be performed Agilent’s qualified service personnel. If
you need the adjustment for your E5071C, it should be sent to the nearest Agilent
Technologies service office.
Table 3-1 Required Adjustment Item after Replacing Assembly
Replaced Assembly Adjustment Item
Writing ID OCXO Frequency Reference AUX Input Synthesizer Gain Virtual Bridge Coefficient Source Output Power Receiver IF Range Receiver Port Characteristics Receiver Absolute Gain Receiver RF Range
OCXO Board
√
Analog Base Module
√ √
Synthesizer Module for Source
√ √
Synthesizer Module for Local
√ √
Level Vernier Module
√
Receiver Module
√ √ √ √ √ √
A21
√
Distributor Module
√ √ √
RF Switch
√ √ √
Writing ID
This item writes the serial number and the option structure into the E5071C.
Required equipment for the writing ID
None
OCXO Adjustment
The purpose of this procedure is to adjust the 10 MHz OCXO.
