Agilent Technologies E5071C Service Guide

140 Chapter 2
Performance Test
E5071C Performance Test Record
Uncorrected System Performance Test
@ Correction: Off, System Correction: On
Option 230
Port 1
-45 ± 0.078 ± 0.021
-50 ± 0.091 ± 0.021
-55 ± 0.106 ± 0.024
-60 ± 0.125 ± 0.024
-65 ± 0.151 ± 0.026
-70 ± 0.189 ± 0.025
-75 ± 0.248 ± 0.011
-80 ± 0.346 ± 0.014
-85 ± 0.509 ± 0.021
-90 ± 0.785 ± 0.033
-95 ± 1.248 ± 0.069
-100 ±2.008 ± 0.060
Power level [dBm] Test limit [dB] Test result [dB] Measurement
uncertainty [dB]
System
performance
Frequency
range [Hz]
Test limit
[dB]
Test result
[dB]
Measurement
uncertainty [dB]
Directivity 9 k - 300 k < -20 0.09
Directivity 300 k -3 G < -25 0.81
Source match 9 k - 300 k < -20 0.05
Source match 300 k -3 G < -25 3.00
Load match 9 k - 300 k < -12 0.04
Load match 300 k - 3 G < -17 0.59
Transmission
Tracking
9 k - 300 k ± 1.5 ± 0.03
Transmission
Tracking
300 k - 3 G ± 1.0 ± 0.20
Reflection
Tracking
9 k - 300 k ± 1.5 ± 0.04
