Agilent Technologies E5071C Service Guide

52 Chapter 2
Performance Test
E5071C Performance Test Record
Frequency Accuracy Test
Option 230, 430
Without Option 1E5
Frequency [Hz] Test limit [Hz] Test result [Hz] Measurement
uncertainty [Hz]
9 k ± 0.045 ± 0.0004
100 k ± 0.5 ± 0.004
50 M ± 250 ± 1.7
134.1 M ± 670.5 ± 4.6
548 M ± 2.74 k ± 16.4
3 G ± 15 k ± 90
With Option 1E5
Frequency [Hz] Test limit [Hz] Test result [Hz] Measurement
uncertainty [Hz]
9 k ± 0.009 ± 0.0003
100 k ± 0.1 ± 0.003
50 M ± 50 ± 0.58
134.1 M ± 134.1 ± 1.6
548 M ± 0.548 k ± 6.4
3 G ± 3 k ± 35
Option 235, 435
Without Option 1E5
Frequency [Hz] Test limit [Hz] Test result [Hz] Measurement
uncertainty [Hz]
100 k ± 0.5 ± 0.004
50 M ± 250 ± 1.7
134.1 M ± 670.5 ± 4.6
548 M ± 2.74 k ± 16.4
3 G ± 15 k ± 90
