254 Chapter 5

Replaceable Parts

Replaceable Parts List

Inverter Assembly

Figure 5-29 Inverter Assembly

e5071cse1093

Table 5-29 Inverter Assembly

Ref.

Desig.

Agilent Part Number Qty. Description

1 E5071-01211 1 BRACKET

2 0950-4420 1 INVERTER

3 0515-1974 2 SCREW-MACH M2.5 x L4 PN T8
