Chapter 6 297

Replacement Procedure

Level Vernier Module Replacement

6. Replacement Procedure

Figure 6-18 Level Vernier Module Removal

e5071cse1103

Replacement Procedure

Step 1. Replace the level vernier module by inverse procedure of removal.

NOTE Fasten the semi rigid cables using a torque wrench or torque driver set for replacement.
