Agilent Technologies E5071C Service Guide

Chapter 2 75
Performance Test
E5071C Performance Test Record
2. Performance Test
CW Frequency: 8.5 GHz (relative to 0 dBm reference)
Option 280, 285, 480, 485
Power level
[dBm]
Test limit [dB] Test result [dB] Measurement
uncertainty [dB]
-20 ± 0.75 ± 0.24
-17.5 ± 0.75 ± 0.24
-15 ± 0.75 ± 0.24
-12.5 ± 0.75 ± 0.24
-10 ± 0.75 ± 0.24
-7.5 ± 0.75 ± 0.24
-5 ± 0.75 ± 0.24
-2.5 ± 0.75 ± 0.24
2.5 ± 0.75 ± 0.23
5 ± 0.75 ± 0.23
7 ± 0.75 ± 0.23
Trace Noise Test
Option 230
Direction: S11 (Magnitude)
Frequency
Range[Hz]
IF bandwidth
[Hz]
Test limit
[dB rms]
Test result
[dB rms]
Measurement
uncertainty [dB]
9 k - 30 k 3 k < 0.004 0.00009
30 k - 10 M 3 k < 0.003 0.00009
10 M - 3 G 70 k < 0.004 0.00033
Direction: S11 (Phase)
8 ± 0.75 ± 0.23
Power level
[dBm]
Test limit [dB] Test result [dB] Measurement
uncertainty [dB]
Frequency
Range[Hz]
IF bandwidth
[Hz]
Tes t lim i t
[deg rms]
Test result
[deg rms]
Measurement
Uncertaintiy [deg]
9 k - 30 k 3 k < 0.035 0.00077
30 k - 10 M 3 k < 0.02 0.0006
