Agilent Technologies E5071C Service Guide

74 Chapter 2
Performance Test
E5071C Performance Test Record
CW Frequency: 6 GHz (relative to 0 dBm reference)
Option 280, 285, 480, 485
Power level
[dBm]
Test limit [dB] Test result [dB] Measurement
uncertainty [dB]
-20 ± 0.75 ± 0.24
-17.5 ± 0.75 ± 0.24
-15 ± 0.75 ± 0.24
-12.5 ± 0.75 ± 0.24
-10 ± 0.75 ± 0.24
-7.5 ± 0.75 ± 0.24
-5 ± 0.75 ± 0.24
-2.5 ± 0.75 ± 0.24
2.5 ± 0.75 ± 0.23
5 ± 0.75 ± 0.23
7.5 ± 0.75 ± 0.23
9 ± 0.75 ± 0.23
CW Frequency: 7 GHz (relative to 0 dBm reference)
Option 280, 285, 480, 485
Power level
[dBm]
Test limit [dB] Test result [dB] Measurement
uncertainty [dB]
-20 ± 0.75 ± 0.24
-17.5 ± 0.75 ± 0.24
-15 ± 0.75 ± 0.24
-12.5 ± 0.75 ± 0.24
-10 ± 0.75 ± 0.24
-7.5 ± 0.75 ± 0.24
-5 ± 0.75 ± 0.24
-2.5 ± 0.75 ± 0.24
2.5 ± 0.75 ± 0.23
5 ± 0.75 ± 0.23
7.5 ± 0.75 ± 0.23
