32 Chapter 2
Performance Test
3. RF OUTPUT LEVEL ACCURACY AND FLATNESS TEST
3. RF OUTPUT LEVEL ACCURACY AND FLATNESS
TEST
Description
This test checks the level accuracy and frequency flatness of the E5071C test port output
signal. The level accuracy is checked for an output power level setting of 0 dBm at 50 MHz
using a power meter. The frequency flatness is tested by measuring the power level at 26
frequency points from 9 kHz to 8.5 GHz and calculating the differences of the power meter
readings from the level at 50 MHz.
Test equipment
Power meter Agilent E4419A/B
Power sensor Agilent E9304A Opt. H18 or Agilent E9304A
Opt.H19
