Chapter 6 299

Replacement Procedure

Synthesizer Module Replacement

6. Replacement Procedure

Figure 6-19 Synthesizer Module Removal

e5071cse1104

12 3

Replacement Procedure

Step 1. Replace the synthesizer module by inverse procedure of removal.

NOTE Fasten the semi rigid cables using a torque wrench or torque driver set for replacement.
