Agilent Technologies E5071C Service Guide

Chapter 6 307
Replacement Procedure
RF Switch and Distributor Module Replacement for 4-Port model
6. Replacement Procedure
Figure 6-23 RF Switch and Distributor Module Replacement for 4-port model
e5071cse1106
564
7
3
2 1
8
9
Replacement Procedure
Step 1. Replace the switch by inverse procedure of removal.
NOTE Be careful screw (item 4) and screw (item 5) are different.
NOTE Fasten the semi rigid cables using a torque wrench or torque driver set for replacement.
