Chapter 6 317

Replacement Procedure

Inverter Board Replacement

6. Replacement Procedure

Figure 6-30 Inverter Board Removal

e5071cse1112

Replacement Procedure

Step 1. Replace the inverter assembly by inverse procedure of removal.

NOTE Fasten the TORX T15 screws (item 2) using a torque screwdriver (set to 1.02 N-m / 9.0

lb-in).
