Agilent Technologies E5071C

Chapter 6 303
Replacement Procedure
Receiver Module Replacement for 4-Port model
6. Replacement Procedure
Figure 6-21 Receiver Module Removal for 4-port model
e5071cse1105
21
3
4
5
Replacement Procedure
Step 1. Replace the receiver module by inverse procedure of removal.
NOTE Fasten the semi rigid cables using a torque wrench or torque driver set for replacement.
