244 Chapter 5

Replaceable Parts

Replaceable Parts List

PCA Digital Board Assembly

Figure 5-20 PCA Digital Board Assembly

e5071cse1088

Table 5-20 PCA Digital Board Assembly

Ref.

Desig.

Agilent Part Number Qty. Description

1 E5070-66553 1 PCA DIGITAL BRIDGE

2 0515-0430 2 SCREW-MACH M3.0 x 6 PN T10

3 E5071-01210 1 STAY
