Agilent Technologies E5071C Service Guide

56 Chapter 2
Performance Test
E5071C Performance Test Record
RF Output Level Accuracy and Flatness Test
1. Power Sensor: E9304A Option H18
Level Accuracy Test (@ Port 1)
Power level
[dBm]
Frequency
[Hz]
Test limit
[dB]
Test result
[dB]
Measurement
uncertainty [dB]
0 50 M ± 0.65 ± 0.19
Level Flatness Test (@ Port 1) (at 0 dBm, relative to 50 MHz reference)
Option 230, 430
Frequency [Hz] Test limit [dB] Test result [dB] Measurement
uncertainty [dB]
9 k ± 1.0 ± 0.27
20 k ± 1.0 ± 0.27
70 k ± 1.0 ± 0.27
100 k ± 1.0 ± 0.27
300 k ± 1.0 ± 0.27
1 M ± 1.0 ± 0.23
68 M ± 1.0 ± 0.23
68M + 1 ± 1.0 ± 0.23
550 M ± 1.0 ± 0.24
1.05 G ± 1.0 ± 0.24
1.55 G ± 1.0 ± 0.23
2.05 G ± 1.0 ± 0.23
2.55 G ± 1.0 ± 0.23
3 G ± 1.0 ± 0.23
Option 235, 435
Frequency [Hz] Test limit [dB] Test result [dB] Measurement
uncertainty [dB]
100 k ± 1.0 ± 0.27
300 k ± 1.0 ± 0.27
1 M ± 1.0 ± 0.23
