Chapter 6 325

Replacement Procedure

Probe Power and Power Switch Board Replacement

6. Replacement Procedure

Figure 6-34 Probe Power and Power Switch Board Removal

e5071cse1117

3 2 4 6

Replacement Procedure

Step 1. Replace the prove power board or switch board by inverse procedure of removal.
