Chapter 6 277
Replacement Procedure
Removable Hard Disk Drive Replacement Option 017
6. Replacement Procedure
Figure 6-7 Removable Hard Disk Drive Removal Option 017
e5071cse3004
142
3
7
8
6
5
5
Replacement Procedure
Step 1. Replace the removable hard disk drive by inverse procedure of removal.
NOTE Fasten the TORX T10 screws (item 7) using a torque screwdriver.
Step 2. Insert the hard disk into the slot.
Step 3. Turn the key to the left until it is locked, then remove the key.
Step 4. Restore backup files onto the new removable hard disk drive as described in “Restore
Backup Files onto the New Hard Disk Drive” on page 272.
Step 5. Calibrate the touch screen as described in “Calibration of the Touch Screen” on page 272.
To Next Page
