Chapter 6 281
Replacement Procedure
Hard Disk Drive Replacement Option 019
6. Replacement Procedure
Replacement Procedure
Step 1. Paste the heat transfer sheet to the hard disk drive rear side.
Figure 6-10 Removable Hard Disk Drive Removal Option 019
Step 2. Replace the hard disk drive by inverse procedure of removal.
NOTE Fasten the TORX T10 screws (item 3) using a torque driver.
Step 3. Restore backup files onto the new removable hard disk drive as described in “Restore
Backup Files onto the New Hard Disk Drive” on page 272.
Step 4. Calibrate the touch screen as described in “Calibration of the Touch Screen” on page 272.
To Next Page
