E5071C Performance Test Record
Direction: S22 (Magnitude)
Frequency
Range[Hz]
IF bandwidth
[Hz]
Test limit
[dB rms]
Test result
[dB rms]
Measurement
uncertainty [dB]
9 k - 30 k 3 k < 0.004 0.00009
30 k - 10 M 3 k < 0.003 0.00009
10 M - 3 G 70 k < 0.004 0.00033
Direction: S22 (Phase)
Frequency
Range[Hz]
IF bandwidth
[Hz]
Tes t lim i t
[deg rms]
Test result
[deg rms]
Measurement
Uncertaintiy [deg]
9 k - 30 k 3 k < 0.035 0.00077
30 k - 10 M 3 k < 0.02 0.0006
10 M - 3 G 70 k < 0.035 0.001
Direction: S21 (Magnitude)
Frequency
Range[Hz]
IF bandwidth
[Hz]
Test limit
[dB rms]
Test result
[dB rms]
Measurement
uncertainty [dB]
9 k - 30 k 3 k < 0.004 0.00009
30 k - 10 M 3 k < 0.003 0.00009
10 M - 3 G 70 k < 0.004 0.00033
Direction: S21 (Phase)
Frequency
Range[Hz]
IF bandwidth
[Hz]
Tes t lim i t
[deg rms]
Test result
[deg rms]
Measurement
Uncertaintiy [deg]
9 k - 30 k 3 k < 0.035 0.00077
30 k - 10 M 3 k < 0.02 0.0006
10 M - 3 G 70 k < 0.035 0.001
10 M - 3 G 70 k < 0.035 0.001
Frequency
Range[Hz]
IF bandwidth
[Hz]
Tes t lim i t
[deg rms]
Test result
[deg rms]
Measurement
Uncertaintiy [deg]
