Agilent Technologies E5071C Service Guide

Chapter 2 141
Performance Test
E5071C Performance Test Record
2. Performance Test
Port 2
System
performance
Frequency
range [Hz]
Test limit
[dB]
Test result
[dB]
Measurement
uncertainty [dB]
Directivity 9 k - 300 k < -20 0.09
Directivity 300 k -3 G < -25 0.81
Source match 9 k - 300 k < -20 0.05
Source match 300 k -3 G < -25 3.00
Load match 9 k - 300 k < -12 0.04
Load match 300 k - 3 G < -17 0.59
Transmission
Tracking
9 k - 300 k ± 1.5 ± 0.03
Transmission
Tracking
300 k - 3 G ± 1.0 ± 0.20
Reflection
Tracking
9 k - 300 k ± 1.5 ± 0.03
Reflection
Tracking
300 k - 3G ± 1.0 ± 0.03
Option 235
Port 1
Reflection
Tracking
300 k - 3G ± 1.0 ± 0.04
System
performance
Frequency
range [Hz]
Test limit
[dB]
Test result
[dB]
Measurement
uncertainty [dB]
System
performance
Frequency
range [Hz]
Test limit
[dB]
Test result
[dB]
Measurement
uncertainty [dB]
Directivity 100 k - 300 k < -20 0.09
Directivity 300 k -3 G < -25 0.81
Source match 100 k - 300 k < -20 0.05
Source match 300 k -3 G < -25 3.00
Load match 100 k - 300 k < -12 0.04
Load match 300 k - 3 G < -17 0.59
Transmission
Tracking
100 k - 300 k ± 1.5 ± 0.03
