Table 5-17 Removable Hard Disk Drive Assembly
Ref.
Desig.
Agilent Part Number Qty. Description
1 E5052-60101 1 REMOVABLE HDD 2.5INCH RECEIVING FRAME ASSY
2 E5070-66538 1 CONNECTOR BD PCA
3 E5070-61668 1 FLAT CBL ASSY
4 E5071-82301 1 HDD INSTALLED (Service Center Only)
5 E5070-00650 1 PLATE BOTTOM
6 0515-2146 4 SCREW-MACH M3.0 x L4 FL T10
7 E5070-04006 2 COVER
8 0515-1946 4 SCREW-MACH M3.0 x L6 FL T10
9 E5070-00655 1 PLATE FRONT
10 0515-2146 2 SCREW-MACH M3.0 x L4 FL T10
11 E5070-87301 2 LABEL
12 1390-1375 1 HDD KEYS
13 7121-5441 1 LABEL (Service Center Only)
240 Chapter 5
