Agilent Technologies E5071C Service Guide

Chapter 7 329
Post-Repair Procedures
Post-Repair Procedures
7. Post-Repair Procedures
Synthesizer
Module
Perform the following required
adjustment.
- Synthesizer Gain
- Source Output Power
- Receiver Port Characteristics
- Receiver Absolute Gain
Perform “To Execute the diagnostics Test” on
page 187
Perform the follwoing performance test.
- Frequency Accuracy Test
- RF Output Level Accuracy and Flatness Test
- RF Output Level Linearity Test
- Trace Noise Test
- Crosstalk Test
- System Dynamic Range Test
- Dynamic Accuracy test
- Uncorrected System Performance Test
Receiver
Module
Perform the following required
adjustments.
- Source Output Power
- Receiver IF Range
- Receiver Port Characteristics
- Receiver Absolute Gain
Perform “To Execute the diagnostics Test” on
page 187
Perform the follwoing performance test.
- Trace Noise Test
- Crosstalk Test
- System Dynamic Range Test
- Dynamic accuracy test
- Uncorrected system performance
Level Vernier
Module
Perform the following required
adjustments.
- Source Output Power
- Receiver Absolute Gain
Perform “To Execute the diagnostics Test” on
page 187
Perform the follwoing performance test.
- Frequency Accuracy Test
- RF Output Level Accuracy and Flatness Test
- RF Output Level Linearity Test
- Trace Noise Test
- Crosstalk Test
- System Dynamic Range Test
- Dynamic Accuracy test
- Uncorrected System Performance Test
Table 7-1 Post-Repair Procedures
Replaced
Assembly or
Part
Required Adjustments
Correction Constants (CC)
Verification
