Agilent Technologies E5071C Service Guide

42 Chapter 2
Performance Test
E5071C Performance Test Calculation Sheet
(Option 280, 480)
Frequency [Hz] Power meter reading [dBm] Test resu lt equation
[a] [REF]
50 M ——————
9 k —————— a - REF
20 k —————— a - REF
70 k —————— a - REF
100 k —————— a - REF
300 k —————— a - REF
1 M —————— a - REF
68 M —————— a - REF
68 M + 1 —————— a - REF
550 M —————— a - REF
1.05 G —————— a - REF
1.55 G —————— a - REF
2.05 G —————— a - REF
2.55 G —————— a - REF
3.00 G —————— a - REF
3.025 G —————— a - REF
3.525 G —————— a - REF
4.025 G —————— a - REF
4.525 G —————— a - REF
5.025 G —————— a - REF
5.525 G —————— a - REF
6.025 G —————— a - REF
6.525 G —————— a - REF
7.025 G —————— a - REF
7.525 G —————— a - REF
8.025 G —————— a - REF
8.5 G —————— a - REF
(Option 285, 485)
