Rockwell Automation Publication 1769-UM022C-EN-P - June 2018 69

Communicate Over Networks Chapter 5

3. Click Time-based and then Generate.

4. Click OK.

Change the SNN of Safety I/O Modules on the CIP Safety Networks

1. In the Controller Organizer, double-click the first safety I/O module

underneath the Ethernet network to view the General tab.

2. Click to the right of the safety network number to open the Safety

Network Number dialog box.

Default Chapter3
