Rockwell Automation Publication 1769-UM022C-EN-P - June 2018 95

Add and Configure Standard I/O Modules Chapter 6

This graphic shows 1769-HSC high-speed counter modules that are installed

in a 1769-L36ERMS control system that meet the power supply

distance rating of the module.

For more information about the power supply distance rating for a Compact

I/O module, see CompactLogix™ Selection Guide, publication 1769-SG001

1769-HSC High-speed Counter Modules Installed in a 1769-L36ERMS

Control System Meeting the Power Supply Distance Rating Requirements

of the High-speed Counter Module

Local Bank

Extra Bank
