1.10.3.21. HS TIMER 3 CURRENT VALUE LO REGISTER
Offset: 0x7C
Register Name: HS_TMR3_CURNT_LO_REG
Bit
Read/
Write
Default/He
x
Description
31:0
R/W
x
HS_TMR3_CUR_VALUE_LO.
High Speed Timer 3 Current Value [31:0].
1.10.3.22. HS TIMER 3 CURRENT VALUE HI REGISTER
Offset: 0x80
Register Name: HS_TMR3_CURNT_HI_REG
Bit
Read/
Write
Default/He
x
Description
31:24
/
/
/
23:0
R/W
x
HS_TMR3_CUR_VALUE_HI.
High Speed Timer 3 Current Value [55:32].
Note:
1) High speed timer 1 current value is a 56-bit down-counter (from interval value to 0).
2) The current value register is a 56-bit register. When read or write the current value, the Low
register should be read or written first.
