1.19.4.29. PD CONFIGURE REGISTER 1
Offset: 0x70
Register Name: PD_CFG1
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31
/
/
/
30:28
R/W
0
PD15_SELECT
000: Input 001: Output
010: LCD0_D15 011: LVDS1_VN2
100: Reserved 101: Reserved
110: Reserved 111: Reserved
27
/
/
/
26:24
R/W
0
PD14_SELECT
000: Input 001: Output
010: LCD0_D14 011: LVDS1_VP2
100: Reserved 101: Reserved
110: Reserved 111: Reserved
23
/
/
/
22:20
R/W
0
PD13_SELECT
000: Input 001: Output
010: LCD0_D13 011: LVDS1_VN1
100: Reserved 101: Reserved
110: Reserved 111: Reserved
19
/
/
/
18:16
R/W
0
PD12_SELECT
000: Input 001: Output
010: LCD0_D12 011: LVDS1_VP1
100: Reserved 101: Reserved
110: Reserved 111: Reserved
15
/
/
/
14:12
R/W
0
PD11_SELECT
000: Input 001: Output
010: LCD0_D11 011: LVDS1_VN0
100: Reserved 101: Reserved
110: Reserved 111: Reserved
11
/
/
/
10:8
R/W
0
PD10_SELECT
