A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 267 / 812
Bit
Read/Write
Default
Description
31
/
/
/
30:28
R/W
0
PE7_SELECT
000: Input 001: Output
010: TS0_D3 011: CSI0_D3
100: Reserved 101: Reserved
110: Reserved 111: Reserved
27
/
/
/
26:24
R/W
0
PE6_SELECT
000: Input 001: Output
010: TS0_D2 011: CSI0_D2
100: Reserved 101: Reserved
110: Reserved 111: Reserved
23
/
/
/
22:20
R/W
0
PE5_SELECT
000: Input 001: Output
010: TS0_D1 011: CSI0_D1
100: SMC_VPPEN 101: Reserved
110: Reserved 111: Reserved
19
/
/
/
18:16
R/W
0
PE4_SELECT
000: Input 001: Output
010: TS0_D0 011: CSI0_D0
100: Reserved 101: Reserved
110: Reserved 111: Reserved
15
/
/
/
14:12
R/W
0
PE3_SELECT
000: Input 001: Output
010: TS0_DVLD 011: CSI0_VSYNC
100: Reserved 101: Reserved
110: Reserved 111: Reserved
11
/
/
/
10:8
R/W
0
PE2_SELECT
000: Input 001: Output
010: TS0_SYNC 011: CSI0_HSYNC
100: Reserved 101: Reserved
