A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 268 / 812
Offset: 0x90
Register Name: PE_CFG0
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
110: Reserved 111: Reserved
7
/
/
/
6:4
R/W
0
PE1_SELECT
000: Input 001: Output
010: TS0_ERR 011: CSI0_CK
100: Reserved 101: Reserved
110: Reserved 111: Reserved
3
/
/
/
2:0
R/W
0
PE0_SELECT
000: Input 001: Output
010: TS0_CLK 011: CSI0_PCK
100: Reserved 101: Reserved
110: Reserved 111: Reserved
1.19.4.38. PE CONFIGURE REGISTER 1
Offset: 0x94
Register Name: PE_CFG1
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:15
/
/
/
14:12
R/W
0
PE11_SELECT
000: Input 001: Output
010: TS0_D7 011: CSI0_D7
100: Reserved 101: Reserved
110: Reserved 111: Reserved
11
/
/
/
10:8
R/W
0
PE10_SELECT
000: Input 001: Output
010: TS0_D6 011: CSI0_D6
100: Reserved 101: Reserved
110: Reserved 111: Reserved
7
/
/
/
