A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 269 / 812
Offset: 0x94
Register Name: PE_CFG1
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
6:4
R/W
0
PE9_SELECT
000: Input 001: Output
010: TS0_D5 011: CSI0_D5
100: Reserved 101: Reserved
110: Reserved 111: Reserved
3
/
/
/
2:0
R/W
0
PE8_SELECT
000: Input 001: Output
010: TS0_D4 011: CSI0_D4
100: Reserved 101: Reserved
110: Reserved 111: Reserved
1.19.4.39. PE CONFIGURE REGISTER 2
Offset: 0x98
Register Name: PE_CFG2
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:0
/
/
/
1.19.4.40. PE CONFIGURE REGISTER 3
Offset: 0x98
Register Name: PE_CFG2
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:0
/
/
/
1.19.4.41. PE DATA REGISTER
Offset: 0xA0
Register Name: PE_DAT
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
