Offset: 0xB8
Register Name: MP_ROPIDX0CTL_REG
Bit
Read/W
rite
Default/H
ex
Description
9:6
R/W
0
NOD4_CTL
Index 0 node4 setting ( channel 0’ and channel 1’ mix logic )
0:and
1:or
2:xor
3:add in byte
4:add in word (32bit)
5:multiply in byte
6:multiply in word (32bit)
7:channel 0’ sub channel 1’ in byte
8:channel 0’ sub channel 1’ in word (32bit)
Other: Reserved
5
R/W
0
NOD3_CTL
Index 0 node3 setting ( channel 2’ not logic )
0:by-pass
1:not
4
R/W
0
NOD2_CTL
Index 0 node2 setting ( channel 1’ not logic )
0:by-pass
1:not
3
R/W
0
NOD1_CTL
Index 0 node1 setting ( channel 0’ not logic)
0:by-pass
1:not
2:0
R/W
0
NOD0_CTL
Index 0 node0 setting ( sorting control )
0:012
1:021
2:102
3:120
4:201
5:210
Other: Reserved
Note: the result of the add or multiply operation will select the high 8 (byte operation) or 32bits (word
operation).
