4.1.5.6. CSI CHANNEL_0 FIFO 0 OUTPUT BUFFER-B ADDRESS REGISTER
Offset Address: 0X0014
Register Name: CSI0_C0_F0_BUFB_REG
Bit
Read/W
rite
Default/
Hex
Description
31:00
R/W
0
C0F0_BUFB
FIFO 0 output buffer-B address
4.1.5.7. CSI CHANNEL_0 FIFO 1 OUTPUT BUFFER-A ADDRESS REGISTER
Offset Address: 0X0018
Register Name: CSI0_C0_F1_BUFA_REG
Bit
Read/W
rite
Default/
Hex
Description
31:00
R/W
0
C0F1_BUFA
FIFO 1 output buffer-A address
4.1.5.8. CSI CHANNEL_0 FIFO 1 OUTPUT BUFFER-B ADDRESS REGISTER
Offset Address: 0X001C
Register Name: CSI0_C0_F1_BUFB_REG
Bit
Read/W
rite
Default/
Hex
Description
31:00
R/W
0
C0F1_BUFB
FIFO 1 output buffer-B address
4.1.5.9. CSI CHANNEL_0 FIFO 2 OUTPUT BUFFER-A ADDRESS REGISTER
Offset Address: 0X0020
Register Name: CSI0_C0_F2_BUFA_REG
Bit
Read/W
rite
Default/
Hex
Description
31:00
R/W
0
C0F2_BUFA
FIFO 2 output buffer-A address
4.1.5.10. CSI CHANNEL_0 FIFO 2 OUTPUT BUFFER-B ADDRESS REGISTER
Offset Address: 0X0024
Register Name: CSI0_C0_F2_BUFB_REG
