Bit
Read/W
rite
Default/
Hex
Description
31:00
R/W
0
C0F2_BUFB
FIFO 2 output buffer-B address
4.1.5.11. CSI CHANNEL_0 OUTPUT BUFFER CONTROL REGISTER
Offset Address: 0X0028
Register Name: CSI0_C0_BUF_CTL_REG
Bit
Read/W
rite
Default/
Hex
Description
31:03
/
/
/
02
R/W
0
DBN
Buffer selected at next storing for CSI
0: Next buffer selection is buffer-A
1: Next buffer selection is buffer-B
01
R
0
DBS
output buffer selected status
0: Selected output buffer-A
1: Selected output buffer-B
00
R/W
0
DBE
Double buffer mode enable
0: disable
1: enable
If the double buffer mode is disabled, the buffer-A will be always
selected by CSI module.
4.1.5.12. CSI CHANNEL_0 STATUS REGISTER
Offset Address: 0X002C
Register Name: CSI0_C0_BUF_STA_REG
Bit
Read/W
rite
Default/
Hex
Description
31:08
R
0
LUM_STATIS
luminance statistical value
When frame done interrupt flag come, value is ready and will last
until next frame done.
