31:00
R/W
0
C3F2_BUFA
FIFO 2 output buffer-A address
4.1.5.49. CSI CHANNEL_3 FIFO 2 OUTPUT BUFFER-B ADDRESS REGISTER
Offset Address: 0X0324
Register Name: CSI0_C3_F2_BUFB_REG
Bit
Read/W
rite
Default/
Hex
Description
31:00
R/W
0
C3F2_BUFB
FIFO 2 output buffer-B address
4.1.5.50. CSI CHANNEL_3 OUTPUT BUFFER CONTROL REGISTER
Offset Address: 0X0328
Register Name: CSI0_C3_BUF_CTL_REG
Bit
Read/W
rite
Default/
Hex
Description
31:03
/
/
/
02
R/W
0
DBN
Buffer selected at next storing for CSI
0: Next buffer selection is buffer-A
1: Next buffer selection is buffer-B
01
R
0
DBS
output buffer selected status
0: Selected output buffer-A
1: Selected output buffer-B
00
R/W
0
DBE
Double buffer mode enable
0: disable
1: enable
If the double buffer mode is disabled, the buffer-A will be always
selected by CSI module.
