4.1.5.51. CSI CHANNEL_3 STATUS REGISTER
Offset Address: 0X032C
Register Name: CSI0_C3_BUF_STA_REG
Bit
Read/W
rite
Default/
Hex
Description
31:08
R
0
LUM_STATIS
luminance statistical value
When frame done interrupt flag come, value is ready and will last
until next frame done.
For raw data, value = (G>>1+R+G)>>8
For yuv422, value = Y>>8
07:02
/
/
/
01
R
0
VCAP_STA
Video capture in progress
Indicates the CSI is capturing video image data (multiple
frames). The bit is set at the start of the first frame after enabling
video capture. When software disables video capture, it clears
itself after the last pixel of the current frame is captured.
00
R
0
SCAP_STA
Still capture in progress
Indicates the CSI is capturing still image data (single frame). The
bit is set at the start of the first frame after enabling still frame
capture. It clears itself after the last pixel of the first frame is
captured.
For CCIR656 interface, if the output format is frame planar
YCbCr 420 mode, the frame end means the field2 end, the other
frame end means filed end.
4.1.5.52. CSI CHANNEL_3 INTERRUPT ENABLE REGISTER
Offset Address: 0X0330
Register Name: CSI0_C3_INT_EN_REG
Bit
Read/W
rite
Default/
Hex
Description
31:08
/
/
/
07
R/W
0
VS_INT_EN
vsync flag
The bit is set when vsync come. And at this time load the buffer
address for the coming frame. So after this irq come, change the
buffer address could only effect next frame
06
R/W
0
HB_OF_INT_EN
