A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 412 / 812
Offset: 0x008
Register Name: TCON_GINT1_REG
Bit
Read/
Write
Default/
Hex
Description
31:27
/
/
/
26:16
R/W
0
TCON0_Line_Int_Num
scan line for TCON0 line trigger(including inactive lines)
Setting it for the specified line for trigger0.
Note: SY0 is writable only when LINE_TRG0 disable.
15:11
/
/
/
10:0
R/W
0
TCON1_Line_Int_Num
scan line for TCON1 line trigger(including inactive lines)
Setting it for the specified line for trigger 1.
Note: SY1 is writable only when LINE_TRG1 disable.
5.1.4.4. TCON FRM CONTROL REGISTER
Offset: 0x010
Register Name: TCON_FRM_CTL_REG
Bit
Read/
Write
Default/
Hex
Description
31
R/W
0
TCON0_Frm_En
0:disable
1:enable
30:7
/
/
/
6
R/W
0
TCON0_Frm_Mode_R
0: 6bit frm output
1: 5bit frm output
5
R/W
0
TCON0_Frm_Mode_G
0: 6bit frm output
1: 5bit frm output
4
R/W
0
TCON0_Frm_Mode_B
0: 6bit frm output
1: 5bit frm output
3:2
/
/
/
1:0
R/W
0
/
