A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 425 / 812
5.1.4.24. TCON1 BASIC TIMING REGISTER0
Offset: 0x094
Register Name: TCON1_BASIC0_REG
Bit
Read/
Write
Default/
Hex
Description
31:28
/
/
/
27:16
R/W
0
TCON1_XI
source width is X+1
15:12
/
/
/
11:0
R/W
0
TCON1_YI
source height is Y+1
5.1.4.25. TCON1 BASIC TIMING REGISTER1
Offset: 0x098
Register Name: TCON1_BASIC1_REG
Bit
Read/
Write
Default/
Hex
Description
31:28
/
/
/
27:16
R/W
0
LS_XO
width is LS_XO+1
15:12
/
/
/
11:0
R/W
0
LS_YO
width is LS_YO+1
NOTE: this version LS_YO = TCON1_YI
5.1.4.26. TCON1 BASIC TIMING REGISTER2
Offset: 0x09C
Register Name: TCON1_BASIC2_REG
Bit
Read/
Write
Default/
Hex
Description
31:28
/
/
/
27:16
R/W
0
TCON1_XO
width is TCON1_XO+1
15:12
/
/
/
