A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 429 / 812
Offset: 0x100
Register Name: TCON_CEU_CTL_REG
Bit
Read/
Write
Default/H
ex
Description
31
R/W
0
CEU_en
0: bypass
1: enable
30:0
/
/
/
5.1.4.33. TCON CEU COEFFICENT REGISTER
Offset: 0x110
Register Name: TCON_CEU_MUL_RR_REG
Bit
Read/
Write
Default/
Hex
Description
31:13
/
/
/
12:0
R/W
0
Coef_Value
signed 13bit value, range of (-16,16)
Offset: 0x114
Register Name: TCON_CEU_MUL_RG_REG
Bit
Read/
Write
Default/
Hex
Description
31:13
/
/
/
12:0
R/W
0
Coef_Value
signed 13bit value, range of (-16,16)
Offset: 0x118
Register Name: TCON_CEU_MUL_RB_REG
Bit
Read/
Write
Default/
Hex
Description
31:13
/
/
/
12:0
R/W
0
Coef_Value
signed 13bit value, range of (-16,16)
Offset: 0x11c
Register Name: TCON_CEU_ADD_RC_REG
Bit
Read/
Write
Default/
Hex
Description
31:19
/
/
/
