Allwinner A20 - Page 430

A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 430 / 812
Offset: 0x11c
Register Name: TCON_CEU_ADD_RC_REG
Bit
Read/
Write
Default/
Hex
Description
18:0
R/W
0
Coef_Value
signed 19bit value, range of (-16384, 16384)
Offset: 0x120
Register Name: TCON_CEU_MUL_GR_REG
Bit
Read/
Write
Default/
Hex
Description
31:13
/
/
/
12:0
R/W
0
Coef_Value
signed 13bit value, range of (-16,16)
Offset: 0x124
Register Name: TCON_CEU_MUL_GG_REG
Bit
Read/
Write
Default/
Hex
Description
31:13
/
/
/
12:0
R/W
0
Coef_Value
signed 13bit value, range of (-16,16)
Offset: 0x128
Register Name: TCON_CEU_MUL_GB_REG
Bit
Read/
Write
Default/
Hex
Description
31:13
/
/
/
12:0
R/W
0
Coef_Value
signed 13bit value, range of (-16,16)
Offset: 0x12C
Register Name: TCON_CEU_ADD_GC_REG
Bit
Read/
Write
Default/
Hex
Description
31:19
/
/
/
18:0
R/W
0
Coef_Value
signed 19bit value, range of (-16384, 16384)
Offset: 0x130
Register Name: TCON_CEU_MUL_BR_REG
