A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 431 / 812
Bit
Read/
Write
Default/
Hex
Description
31:13
/
/
/
12:0
R/W
0
Coef_Value
signed 13bit value, range of (-16,16)
Offset: 0x134
Register Name: TCON_CEU_MUL_BG_REG
Bit
Read/
Write
Default/
Hex
Description
31:13
/
/
/
12:0
R/W
0
Coef_Value
signed 13bit value, range of (-16,16)
Offset: 0x138
Register Name: TCON_CEU_MUL_BB_REG
Bit
Read/
Write
Default/
Hex
Description
31:13
/
/
/
12:0
R/W
0
Coef_Value
signed 13bit value, range of (-16,16)
Offset: 0x13C
Register Name: TCON_CEU_ADD_BC_REG
Bit
Read/
Write
Default/
Hex
Description
31:19
/
/
/
18:0
R/W
0
Coef_Value
signed 19bit value, range of (-16384, 16384)
Offset: 0x140
Register Name: TCON_CEU_RANGE_R_REG
Bit
Read/
Write
Default/
Hex
Description
31:24
/
/
/
23:16
R/W
0
Coef_Range_Min
unsigned 8bit value, range of [0,255]
