A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 501 / 812
Offset: 0x94
Register Name: DEFE_CSC_COEF21_REG
Bit
Read/
Write
Default/
Hex
Description
12:0
R/W
0x0
COEF
the V/B coefficient
the value equals to coefficient*2
10
5.3.4.34. DEFE_CSC_COEF22_REG
Offset: 0x98
Register Name: DEFE_CSC_COEF22_REG
Bit
Read/
Write
Default/
Hex
Description
31:13
/
/
/
12:0
R/W
0x0
COEF
the V/B coefficient
the value equals to coefficient*2
10
5.3.4.35. DEFE_CSC_COEF23_REG
Offset: 0x9C
Register Name: DEFE_CSC_COEF23_REG
Bit
Read/
Write
Default/
Hex
Description
31:14
/
/
/
13:00
R/W
0x0
CONT
the V/B constant
the value equals to coefficient*2
4
5.3.4.36. DEFE_DI_CTRL_REG
Offset: 0xA0
Register Name: DEFE_DI_CTRL_REG
Bit
Read/
Write
Default/
Hex
Description
31:26
/
/
/
