A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 500 / 812
Offset: 0x88
Register Name: DEFE_CSC_COEF12_REG
Bit
Read/
Write
Default/
Hex
Description
12:0
R/W
0x0
COEF
the U/R coefficient
the value equals to coefficient*2
10
5.3.4.31. DEFE_CSC_COEF13_REG
Offset: 0x8C
Register Name: DEFE_CSC_COEF13_REG
Bit
Read/
Write
Default/
Hex
Description
31:14
/
/
/
13:00
R/W
0x0
CONT
the U/R constant
the value equals to coefficient*2
4
5.3.4.32. DEFE_CSC_COEF20_REG
Offset: 0x90
Register Name: DEFE_CSC_COEF20_REG
Bit
Read/
Write
Default
/Hex
Description
31:13
/
/
/
12:0
R/W
0x0
COEF
the V/B coefficient
the value equals to coefficient*2
10
5.3.4.33. DEFE_CSC_COEF21_REG
Offset: 0x94
Register Name: DEFE_CSC_COEF21_REG
Bit
Read/
Write
Default/
Hex
Description
31:13
/
/
/
