A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 499 / 812
Bit
Read/
Write
Default/H
ex
Description
31:14
/
/
/
13:0
R/W
0x0
CONT
the Y/G constant
the value equals to coefficient*2
4
5.3.4.28. DEFE_CSC_COEF10_REG
Offset: 0x80
Register Name: DEFE_CSC_COEF10_REG
Bit
Read/
Write
Default/
Hex
Description
31:13
/
/
/
12:0
R/W
0x0
COEF
the U/R coefficient
the value equals to coefficient*2
10
5.3.4.29. DEFE_CSC_COEF11_REG
Offset: 0x84
Register Name: DEFE_CSC_COEF11_REG
Bit
Read/
Write
Default/
Hex
Description
31:13
/
/
/
12:0
R/W
0x0
COEF
the U/R coefficient
the value equals to coefficient*2
10
5.3.4.30. DEFE_CSC_COEF12_REG
Offset: 0x88
Register Name: DEFE_CSC_COEF12_REG
Bit
Read/
Write
Default/
Hex
Description
31:13
/
/
/
