Allwinner A20 - Page 498

A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 498 / 812
5.3.4.24. DEFE_CSC_COEF00_REG
Offset: 0x70
Register Name: DEFE_CSC_COEF00_REG
Bit
Read/
Write
Default/
Hex
Description
31:13
/
/
/
12:0
R/W
0x0
COEF
the Y/G coefficient
the value equals to coefficient*2
10
5.3.4.25. DEFE_CSC_COEF01_REG
Offset: 0x74
Register Name: DEFE_CSC_COEF01_REG
Bit
Read/
Write
Default/He
x
Description
31:13
/
/
/
12:0
R/W
0x0
COEF
the Y/G coefficient
the value equals to coefficient*2
10
5.3.4.26. DEFE_CSC_COEF02_REG
Offset: 0x78
Register Name: DEFE_CSC_COEF02_REG
Bit
Read/
Write
Default/H
ex
Description
31:13
/
/
/
12:0
R/W
0x0
COEF
the Y/G coefficient
the value equals to coefficient*2
10
5.3.4.27. DEFE_CSC_COEF03_REG
Offset: 0x7C
Register Name: DEFE_CSC_COEF03_REG
