A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 509 / 812
Offset: 0xF0
Register Name: DEFE_3D_ TB_OFF0_REG
Bit
Read/
Write
Default/
Hex
Description
This value is the start offset of right image in 3D mode
5.3.4.54. DEFE_3D_TB_OFF1_REG
Offset: 0xF4
Register Name: DEFE_3D_ TB_OFF1_REG
Bit
Read/
Write
Default/
Hex
Description
31:21
/
/
/
20:16
R/W
0x0
X_OFFSET1
The x offset of the bottom-right point in the first tile
15:13
/
/
/
12:8
R/W
0x0
Y_OFFSET0
The y offset of the top-left point in the first tile
7:5
/
/
/
4:0
R/W
0x0
X_OFFSET0
The x offset of the top-left point in the first tile
This value is the start offset of right image in 3D mode
5.3.4.55. DEFE_3D_TB_OFF2_REG
Offset: 0xF8
Register Name: DEFE_3D_ TB_OFF2_REG
Bit
Read/
Write
Default/H
ex
Description
31:21
/
/
/
20:16
R/W
0x0
X_OFFSET1
The x offset of the bottom-right point in the first tile
15:13
/
/
/
12:8
R/W
0x0
Y_OFFSET0
The y offset of the top-left point in the first tile
7:5
/
/
/
