Allwinner A20 - Page 520

A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 520 / 812
Offset: 0x400+N*4
Register Name: DEFE_CH0_HORZCOEF0_REGN
Bit
Read/
Write
Default/H
ex
Description
The value equals to coefficient*2
6
15:8
R/W
0x0
TAP1
Horizontal tap1 coefficient
The value equals to coefficient*2
6
7:0
R/W
0x0
TAP0
Horizontal tap0 coefficient
The value equals to coefficient*2
6
5.3.4.77. DEFE_CH0_HORZCOEF1_REGN (N=0 :31)
Offset: 0x480+N*4
Register Name: DEFE_CH0_HORZCOEF1_REGN
Bit
Read/
Write
Default/
Hex
Description
31:24
R/W
0x0
TAP7
Horizontal tap7 coefficient
The value equals to coefficient*2
6
23:16
R/W
0x0
TAP6
Horizontal tap6 coefficient
The value equals to coefficient*2
6
15:8
R/W
0x0
TAP5
Horizontal tap5 coefficient
The value equals to coefficient*2
6
7:0
R/W
0x0
TAP4
Horizontal tap4 coefficient
The value equals to coefficient*2
6
